M·BIOBASE® PPH 230 WF20 nat CI

PP with low viscosity and wood fibres

All information about our compound at a glance

Properties
Values
Processing
Applications

Image dimensions not found

Change image or reupload it

M·BIOBASE® PPH 230 WF20 nat CI

PP with low viscosity and wood fibres

M·BIOBASE® PPH 230 WF20 nat CI is a modern plastic compound with ISCC PLUS certification and thus offers a more sustainable alternative to conventional plastics. With an allocation factor (biomass-balanced proportion) of approx. 80 % and a biobased proportion of 20 % through wood fibre reinforcement it combines sustainability with high functionality.

The material impresses with good rigidity and a very high flowability which makes it easy to process on conventional machines. In addition, the good impact strength ensures reliability in demanding applications. M·BIOBASE® PPH 230 WF20 nat CI is particularly suitable for injection moulding process and can be used for a wide range of applications, including technical components, sports equipment, toys and general consumer goods. Its beautiful wood look also gives the end products an attractive, natural appearance.

Product properties

Icon_check

Certification

ISCC PLUS

Icon_information

Allocation factor

approx. 80 %

Icon_Processing

Processing technology

Injection moulding

Icon_MVR_MFR

MFR (230 °C/2.16 kg)

23 g/10 min

Icon_tensile_modulus

Stiffness

2,670 MPa

Icon_Charpy

Charpy notched

2.2 kJ/m²

Image dimensions not found

Change image or reupload it

Interested? Test our material

We would be happy to make you an offer!

Fill in the contact form here

Indicative technical data M·BIOBASE® PPH 230 WF20 nat CI

English
M·BIOBASE® PPH 230 WF20 nat CI
Unit
Standard
Food contact approval:
no
-
EU 10/2011
Certification:
ISCC PLUS
-
-
Biomass-balanced content (allocation factor)
approx. 80
%
-
Filler
20 % wood fibre
%
Appearance:
brownish, fibres visible
-
-
MFR (230 ˚C/2.16 kg):
23
g/10 min
ISO 1133
Density:
0.96
g/cm³
ISO 1183
Tensile modulus:
2,670
MPa
ISO 527-1/-2
Tensile stength at break:
28
MPa
ISO 527-1/-2
Elongation at break:
5.2
%
ISO 527-1/-2
Charpy notched impact strength (+23 °C):
2.2
kJ/m²
ISO 179-1/1eA
Charpy unnotched impact strength (+23 °C):
13.6
kJ/m²
ISO 179-1/1eU
HDT/B
131
°C
ISO 75/B

Please refer to the product data sheet for details.

Not the right material?

If you need an alternative compound with different material properties, you will find all our materials suitable for injection moulding here:

Overview injection moulding grades

Image dimensions not found

Change image or reupload it

Everything you need to know about processing

Processing instructions

Details on processing, handling and storage as well as processing temperatures and measured values can be found here:

M·BIOBASE® PPH 230 WF20 nat CI

Possible applications

Technical_parts

Technical components

Toys

Toys

Consumer_goods_pot

Consumer goods

Bio-Fed_Clip_RGB_150dpi

Plant clips

Clips_agriculture

Clips

Question_mark

Your application

Disclaimer: The information is based on our current knowledge and experience. A legally binding guarantee of certain properties or suitability for a specific individual case cannot be derived from this information. The information provided here does not release processors and users from carrying out their own tests and investigations in specific individual cases. BIO-FED®, M∙VERA®, M·BIOBASE®, M·CYCLOSE®, AF-Eco®, AF-CirColor®, AF-Carbon® and AF-CirComplex® are registered trademarks of AKRO-PLASTIC GmbH.
